22kV IEC Standard Pin Post Porcelain Ceramic Insulator

Category: Pin Type Insulator

22kV IEC Standard Pin Post Porcelain Ceramic Insulator

22kv 12.5kn Pin Post Insulator for High Voltage
Cat.No		QS11404	QS11405
Class ANSI		PIN POST	PIN POST
Creepage Distance	mm	520	599
Protected Creepage Distance	mm	260	200
Dry Arcing Distance	mm	260	240
Cantilever Strength	kN	12.5	12.5
Power Frequency Withstand Voltage Dry	kV	90	90
Power Frequency Withstand Voltage Wet	kV	65	65
Impulse Withstand Voltage	kV	150	150
Test Voltage to Ground	kV	22	22
1000HZ Maximum RIV at 1000KHz	μV	100	100
Net Weight Each Approx	kg	10	9.2
